Metra Electronics 95-5810 - Kit Assembly; Double DIN Radio Provision

2
95-5810 KIT ASSEMBLY
B
A
DOUBLE DIN RADIO PROVISION
Attach the Double DIN brackets to the
aftermarket radio using the screws
supplied with the radio. (Figure A)
1
Place the Double DIN trim plate over
the radio face then secure the entire
assembly into the sub dash. (Figure B)
2
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
