95-6511 DASH DISASSEMBLY
CHRYSLER TOWN AND COUNTRY 2008-2010
DODGE GRAND CARAVAN 2008-2010
A
B
C
3
1
Lift up on panel above radio then
remove (2) Phillips screws exposed at
front edge of radio trim panel.
(
Figure B)
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
Remove (3) plastic push pins per side
of bottom trim panel then slide panel
toward rear of van to access (2)
screws on bottom of radio trim panel.
(
Figure C)
4
Remove (2) screw covers facing up
above radio then remove the (2)
Phillips screws exposed. (
Figure A)
2
Continued on page 3.
