95-6511 DASH DISASSEMBLY
D
E
12
3
4
5
6 AUX
AUX
SET
VOLUME
PUSH ON
PUSH AUDIO/SELECT
AM
FM
DISC
LIST
MUSIC
TYPE
SEL;ECT
TUNE/SCROLL
SEEKSEEK
SCAN
TIME INFO RW FF
U
F
4
5
Remove (2) Phillips screws exposed
at bottom edge radio trim panel.
(
Figure D)
Remove (4) Phillips screws securing
radio. (
Figure F)
7
Unclip and remove entire panel sur-
rounding radio including climate con-
trols, vents and clock. (
Figure E)
6
Continue to kit assembly.
CHRYSLER TOWN AND COUNTRY 2008-2010
DODGE GRAND CARAVAN 2008-2010
