95-6511 DASH DISASSEMBLY
DODGE AVENGER 2007-2010
A
B
1 2
3
4
5
6 AUX
AUX
SET
VOLUME
PUSH ON
PUSH AUDIO/SELECT
AM
FM
DISC
LIST
MUSIC
TYPE
SEL;ECT
TUNE/SCROLL
SEEKSEEK
SCAN
TIME INFO RW FF
U
C
D
6
1
Unclip the center dash trim panel.
(
Figure B)
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
Remove (4) screws securing the
radio. Disconnect and remove the
radio. (
Figure C)
Remove (3) screws securing the radio
rear support bracket and remove the
bracket. (
Figure D)
4
5
Unclip and remove the center console
trim panel. (
Figure A)
2
Continue to kit assembly.
