Metra Electronics 95-6511 - Dodge Dakota; Mitsubishi Raider Dash Disassembly; Disconnect Battery; Remove Trim Panel Surrounding Radio; Remove Radio

95-6511 DASH DISASSEMBLY
DODGE DAKOTA 2008-2010
MITSUBISHI RAIDER 2008-09
A
12
3
4
5
6 AUX
AUX
SET
VOLUME
PUSH ON
PUSH AUDIO/SELECT
AM
FM
DISC
LIST
MUSIC
TYPE
SEL;ECT
TUNE/SCROLL
SEEKSEEK
SCAN
TIME INFO RW FF
U
B
7
1
Remove (4) Phillips screws securing
the radio. ( Figure B)
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
Unclip and remove the trim panel
surrounding the radio. ( Figure A)
2
Continue to kit assembly.
A
1
Remove (4) 7mm screws securing
the radio. Unplug and remove radio.
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
Unsnap and remove center dash
panel. (
Figure A)
2
Continue to kit assembly.
