Metra Electronics 95-6513B - Dash Disassembly; Remove Dash Panel; Remove Radio Mounting Screws; Remove Radio Bracket

2011 JEEP GRAND CHEROKEE
95-6513B DASH DISASSEMBLY
Unclip and remove panel from
around the radio including the vents
and the climate controls. (Fig. A)
Remove (4) 7MM screws securing
radio to dash to remove. (Fig. B)
Remove (3) 7MM screws securing
the radio bracket to the sub dash.
(Fig. C)
Continue to Kit Preparation ..........
1
2
3
A
B
C
1
