(Figure A)
DASH DISASSEMBLY
With radio delete or Single DIN factory radio:
1. Using Metra’s 86-5618 radio removal tools
pull the factory radio from the dash.
(Figure A)
2. Remove (2) Phillips screws in bottom of
dash opening.
3. Unclip and remove the factory radio
trim panel.
With Double Din factory radio:
1. Using Metra’s 86-3528 radio removal
tools pull the factory radio from the dash.
(Figure A)
2. Remove (2) Phillips screws from the
bottom of the dash opening.
Continue to Kit Assembly
