1. Place the vehicle in park and apply the
parking brake.
2. With the key in the ignition position,
apply the foot brake and place the
shifter in low gear.
3. Tilt the steering wheel all the way down.
4. Unclip the entire dash bezel, unplugging
any wire harnesses necessary to allow
complete removal. (Figure A)
5. Remove the (2) 3/8” hex head screws
securing the radio, then unplug
and remove.
Continue to Kit Preparation
1. Clip the
radio bezel cut template
onto
the factory dash bezel, and then mark
the inside of the opening. (Figure A)
2. Remove the template, and then carefully
cut along the lines. Set aside for
Kit Assembly.
3. Place the
sub-dash cut template
into the
radio cavity in the dash, and then mark
the inside of the opening. (Figure B)
4. Remove the template, and the lower left
speed clip from the cavity, then carefully
cut the shaded areas marked out with a
suitable cutting tool.
5. Insert the
speed clip
provided with the
kit into the lower left position where the
factory clip was removed.
Continue to Kit Assembly
(Figure B)
(Figure A) (Figure A)
DASH DISASSEMBLY KIT PREPARATION
2
Remove shaded area
Remove shaded area
