1. Unclip and remove the dimmer
switch panel then remove (1) Phillips
screw exposed behind. (Figure A)
2. Unclip and remove shifter trim panel.
(Figure B)
3. Remove (1) Phillips screw at bottom of
radio trim panel. (Figure C)
4. Unclip and remove the temperature
control cable under the drivers side
dash from the white plastic bracket.
5. Remove (4) Phillips screws
securing radio.
Continue to kit assembly
Hyundai Elantra 1996-2000
Dash Disassembly 95-7309
(Figure A)
(Figure C)
(Figure B)
