95-7315
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Remove screw cover from back side
of shift knob and remove (2) Phillips
screws. Lift straight up on shift knob
to remove.
(Figure A)
2
2005-2009 HYUNDAI TUCSON
Unclip and remove shift knob trim
panel.
(Figure B)
3
Remove (10) Phillips screws from
dash support under shift knob trim
panel and remove.
(Figure C)
4
DASH DISASSEMBLY
A
B
C
To Next Page
