Metra Electronics 95-7315 - Page 4

95-7315
2
DASH DISASSEMBLY
2005-2009 HYUNDAI TUCSON
Remove (1) Phillips screw from
bottom center of trim panel
surrounding radio including a/c
controls then unclip and remove
panel.
(Figure D-E)
5
D
E
Remove (4) Phillips screws to
remove radio.
(Figure F)
6
F
