95-7315
3
KIT ASSEMBLY
Locate the factory wiring harness
in the dash. Metra recommends
using the proper mating adapter
from Metra or AXXESS.Re-connect
the negative battery terminal and
test the unit for proper operation.
1
A
Snap the Double DIN brackets to
the Double DIN trim plate.
(Figure A)
2
Reassemble dash in reverse order
of disassembly.
4
DOUBLE DIN HEAD UNIT PROVISION/
STACKED ISO DIN HEAD UNIT PROVISION
B
Slide the Double DIN head unit or
stacked ISO head units into the
bracket/trim plate assembly and
secure the Double DIN head unit
or stacked ISO head units to the
assembly using the screws
supplied with the radio.
(Figure B)
3
