95-7321
DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove the trim panel
surrounding the radio and including
the a/c vents.
(Figure A)
2
HYUNDAI ACCENT 2006-2010
KIA RIO / RIO 5 2006-2010
Remove (4) Phillips screws securing
the radio.
(Figure B)
3
A
B
1
To Next Page
