95-7321
DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove the entire panel
surrounding the radio and including
the A/C controls. Note: Start at
bottom of panel.
(Figure A)
2
KIA SPORTAGE 2005-2010
Remove (4) Phillips screws to extract
radio from dash.
(Figure B)
3
A
B
2
To Next Page
