3
95-7325 KIT ASSEMBLY
B
A
STACKED ISO UNITS PROVISION
Slide the stacked ISO units into the
bracket/trim plate assembly and
secure the units to the assembly using
the screws supplied with the units.
(Figure B)
2
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Snap the Double DIN brackets to the
outside edge of the Double DIN trim
plate.
(Figure A)
1
To Next Page
