Metra Electronics 95-7329 - Kia Rondo Dash Disassembly; Remove Shifter Surrounding Panel; Remove Radio Trim Panel; Remove Radio Unit

1. Unclip and remove the panel
surrounding the shifter. (Figure A)
2. Remove (2) Phillips head screws
securing the radio trim panel. Unplug
and remove panel. (Figure B)
3. Remove (4) Phillips screws securing
the radio. Unplug and remove the radio.
(Figure C)
Continue to kit assembly
3
Kia Rondo 2007-2010
Dash Disassembly 95-7329
(Figure A)
(Figure C)
(Figure B)
