Metra Electronics 95-7329 - Kit Assembly: Double DIN Radio Provision; Attach Double DIN Brackets; Mount Double DIN Radio; Connect Wiring and Test

Kit Assembly 95-7329
4
Double DIN radio provision
1. Snap the Double DIN brackets to the
inside edge of the Double DIN trim
plate. (Figure A)
2 Slide the Double DIN radio into the
bracket/trim plate assembly and secure
the radio to the assembly using the
screws supplied with the radio.
(Figure B)
3. Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adapter from Metra or
AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
4. Reassemble dash in reverse order
of disassembly.
(Figure A)
(Figure B)
