Metra Electronics 95-7329 - Kit Assembly: Stacked ISO Mount Unit Provision; Attach Double DIN Brackets; Mount Stacked ISO Units; Connect Wiring and Test

5
Kit Assembly 95-7329
1. Snap the Double DIN brackets to the
inside edge of the Double DIN trim
plate. (Figure A)
2. Slide the stacked ISO units into the
bracket/radio housing assembly and
secure the units to the kit using the
screws supplied with the units.
(Figure B)
3. Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adapter from Metra or
AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
4. Reassemble dash in reverse order
of disassembly.
Stacked ISO mount unit provision
(Figure A)
(Figure B)
