Metra Electronics 95-7377B - Kit Preparation; Kit Assembly

95-7377B
3
(Figure A)(Figure A)
Kit AssemblyKit Preparation
ISO DDIN radio provision
1. Attach the radio brackets to the
radio using the screws supplied
with the radio. (Figure A)
2. Locate the factory wiring harness
and connector in the dash and
complete all necessary connections
to the radio. Metra recommends
using the proper mating adapter
from Metra and/or Axxess. Test the
radio for proper operation.
3. Secure the completed assembly into
the dash using the factory screws.
4. Snap the radio trim panel over the
completed assembly, and then
reassemble the dash in reverse
order of disassembly.
1. Attach the (2) panel clips to the
radio trim panel as shown.
(Figure A)
Continue to Kit Assembly
