95-7866B DASH DISASSEMBLY
ACURA MDX 2001-2006
A
B
1
1
Remove (6) mounting screws and
remove the audio/display unit from
the dash. (
Figure B)
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
3
Remove (8) screws from the audio
unit and (4) screws from the display
unit and remove the brackets from
the audio/display assembly.
4
Unclip and remove trim panel around
radio/display including a/c vents.
(
Figure A)
2
Continue to kit preparation.
