Metra Electronics 95-7866B - Kit Assembly; Double DIN Head Unit Provision; ISO Stacked Head Unit Provision

95-7866B KIT ASSEMBLY
3
DOUBLE DIN HEAD UNIT PROVISION/
ISO STACKED HEAD UNIT PROVISION
1
Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from
Metra or AXXESS. Re-connect the
negative battery terminal and test
the unit for proper operation.
3
Reassemble dash in reverse order of
disassembly.
2
Slide the Double DIN head unit or
stacked ISO head units into the
bracket/radio housing assembly and
secure the Double DIN head unit or
stacked ISO head units to the
assembly using the screws supplied
with the radio.
(Figure A)
* Note: Refer also to the instructions included with the aftermarket radio.
A
