95-7870
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove entire panel sur-
rounding radio and a/c control all the
way over to left side of steering
wheel.
(Figure A)
2
HONDA RIDGELINE 2005-2009
Remove (5) Phillips screws securing
the radio and pocket assembly.
(Figure B)
3
Remove (2) Phillips screws (1 per
side) securing factory pocket to
radio/pocket bracket assembly.
(Figure C, D)
4
DASH DISASSEMBLY
A
B
CD
Continue to kit assembly.
