Metra Electronics 99-1005 User Manual

99-1005 DASH DISASSEMBLY
KIA SEDONA 2002-2005
A
B
1
Disconnect the negative battery-
terminal to prevent an accidental
short circuit.
1
Remove the ashtray and (1) Phillips
screw exposed in the ashtray cavity.
(Figure A)
2
Unclip and remove the small trim
panel from around radio, climate con-
trols and shifter.
(Figure A)
3
Remove (4) Phillips screws from the
radio trim panel then unclip and
remove the panel. (Figure B)
4
Remove (4) Phillips screws securing
radio. Unplug and remove radio.
(Figure C)
5
Continue to kit assembly.
C
