2
99-1005 DASH DISASSEMBLY
B
C
D
A
KIA SPECTRA 2002-2004
(2004 Base and LS models only)
Remove (2) Phillips facing up above
gauge cluster.
(Figure A)
2
Unsnap and remove top portion of
steering wheel column cover.
(Figure B)
3
Remo
ve (4) Phillips screws securing
radio.
(Figure D)
5
Unsnap and remove entire panel from
left side of steering wheel to right side
surrounding radio.
(Figure C)
4
Continue to kit assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
D
isconnect the negative battery-
terminal to prevent an accidental
short circuit.
1
To Next Page
