Metra Electronics 99-1005 User Manual

4
99-1005 KIT ASSEMBLY
B
C
D
A
ISO MOUNT RADIO WITH POCKET PROVISION
Mount the rear support bracket to
the back of the pocket using the
remaining (2) screws supplied with
the kit. (Figure A)
2
Mount the ISO Brackets to the after-
market radio using the screws sup-
plied with the radio. (
Figure B)
3
Slide the radio into the radio open-
ing until the side clips snap into
place. (
Figure C)
4
Snap the trim plate onto the front of
the Radio Housing. ( Figure D)
5
Continue to final assembly.
Note:
To remove the radio from the
radio housing, unclip and remove
ISO trim-plate. Then use a small
flat blade screw driver to release
the ISO snap in brackets and slide
the radio out of the radio housing.
*Note: Refer also to the instructions included with the aftermarket radio.
Mount the pocket to the back of the
radio housing using (2) of the screws
supplied with the kit. ( Figure A)
1
