Metra Electronics 99-1005 User Manual

3
99-1005 KIT ASSEMBLY
B
C
A
DIN RADIO WITH POCKET PROVISION
Mount the rear support bracket to the
back of the pocket using the remaining
(2) screws supplied with the kit.
(Figure A)
2
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Mount the pocket to the back of the
radio housing using (2) of the screws
supplied with the kit. ( Figure A)
1
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs outward. ( Figure B)
3
Slide the aftermarket radio into the
cage until it snaps into place. ( Figure C)
4
• Spectra only skip to final assembly.
