Metra Electronics 99-2004 User Manual

T
WO ON EACH SIDE
OF RADIO HOUSING
99-2004
KIT ASSEMBLY
Remove (2) tabs from the top edge
of the radio housing.
(Figure A)
1
Remove both mounting brackets “B”
from the radio housing. (Figure B)
2
Slide the DIN cage into the radio
housing and secure by bending the
metal locking tabs outward.
(Figure A)
3
Continue with final assembly.
5
Continue with final assembly.
5
Slide the radio into the DIN
cage/housing assembly until it snaps
into place.
(Figure B)
4
Align the holes from the ISO snap in
brackets with the holes in the side of
the radio and mount the brackets to
the radio using screws supplied with
the radio.
(Figure A)
3
Slide the radio bracket assembly into
the radio housing until the assembly
snaps into place. Snap the ISO
Trimplate over the unit.
(Figure B)
4
DIN RADIO PROVISION
1997-2001 CADILLA
C CATERA
A
B
A
B
A
B
ISO RADIO PROVISION
2

Metra Electronics 99-2004 Specifications

General

Brand	Metra Electronics
Model	99-2004
Category	Automobile Accessories
Language	English
