6 3
Locate the factory wiring har-
ness in the dash. Metra
recommends using the prop-
er mating adapters (included)
from Metra and AXXESS to
integrate your new radio.
Re-connect the negative bat-
tery terminal and test the unit
for proper operation.
Slide the DIN cage into the
Radio Housing and secure
by bending the metal locking
tabs down. (Fig. A)
Snap the pocket into the
bottom opening of the radio
housing. (Fig. B)
Slide the aftermarket head
unit into the cage and se-
cure. (Fig. B)
Continue to “Audio Wiring”....
1
2
3
4
A
B
FORD TAURUS 2004- 2007
DIN HEAD UNIT PROVISION
5
......... Continued from Pg.5
Snap the double DIN trim
plate into the radio housing.
(Fig. B)
Continue to “Audio Wiring”......
FORD TAURUS 2004- 2007
DDIN/STACKED ISO DIN
HEAD UNIT PROVISION
B
99-571999-5719
