99-6503
DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Remove the ashtray by pressing
down on the inner spring clip.
(Concorde only)
2
CHRYSLER 300M 1999-2004/CONCORDE 1998-2004
CHRYSLER LHS 1998-2001/DODGE INTREPID 1998-2004
Unclip gear shifter trim panel and
slide trim panel toward the rear of
the vehicle.
3
Unclip dash trim panel and discon-
nect the wire to the trim panel.
4
Remove (4) Phillips head screws
securing the radio. Disconnect and
remove the radio. Skip to kit assem-
bly page.
5
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip power window control panel.
Disconnect and remove panel.
2
CHRYSLER PT CRUISER 2001-2005
Pull off climate control knobs.
3
Unclip and remove the dash trim
panel.
4
Remove (4) Phillips head screws
securing the radio. Disconnect and
remove the radio. Skip to kit assem-
bly page.
5
1
