Metra Electronics 99-6503 - Dodge Neon;Plymouth Neon Dash Disassembly; Dodge Ram Dash Disassembly

3
99-6503
DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Pull off climate control knobs.
2
DODGE NEON 2000-2006
PLYMOUTH NEON 2000-2001
Unclip and remove ac/heater vents.
3
Remove (1) Phillips head screw from
each vent cavity.
4
Unclip and remove dash trim panel.
5
Remove (4) Phillips head screws
securing the radio. Disconnect and
remove the radio. Skip to kit assem-
bly page.
6
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip the top edge of the trim panel
below the steering column. (It is not
necessary to completely remove this
panel).
2
DODGE RAM 2002-2005
Remove (1) Phillips head screw from
below right ac/heater vent.
3
Unclip and remove dash trim panel.
4
Remove (4) Phillips head screws
securing the radio. Disconnect and
remove the radio. Skip to kit assem-
bly page.
5
