Metra Electronics 99-6503 - Jeep Liberty Dash Disassembly; Jeep Wrangler Dash Disassembly

6
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Remove ashtray and remove one
Phillips screw exposed.
2
JEEP LIBERTY 2002-2006
Unclip and remove radio/ climate
control panel.
3
Remove (4) Phillips screws securing
radio. Disconnect and remove radio.
Skip to kit assembly page.
4
1
2
3
4
POWER
OUTLET
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unsnap and remove defroster grille
panel near windshield.
2
JEEP WRANGLER 2003-2006
Remove two Phillips screws exposed
at the top of the center dash panel
and unsnap and remove panel.
3
Remove glove box door to access
one 10mm nut on back of radio.
4
Remove (4) Phillips screws securing
radio. Disconnect and remove radio.
Skip to kit assembly page.
5
99-6503
DASH DISASSEMBLY
