8
99-6505
KIT ASSEMBLY
ISO DIN HEAD UNIT PROVISION
Slide the head unit/bracket assembly
into the radio opening until the side
clips engage.
(Figure B)
2
Snap the ISO Trimplate over the head
unit.
(Figure B)
3
Align the holes in the ISO Snap In
Brackets with the holes in the head
unit and mount the brackets to the
head unit with the screws supplied
with the unit.
(Figure A)
1
A
B
To Next Page
