99-6505
DASH DISASSEMBLY
6
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Using a small flat blade screw driver,
pry up on center console trim panel.
(Be careful not to scratch the trim
panel)
(Figure A)
2
DODGE VIPER 2003-2009
Loosen the shifter lock nut below
center console trim panel
(Figure A)
and unscrew the shifter knob.
(Figure B)
3
Unplug electrical connectors and
remove center console trim panel.
(Figure C)
4
Remove (6) Allen screws from
radio/climate control trim panel and
(1) Phillips screw at the bottom of
the panel.
5
Unplug electrical connectors and
remove the panel.
(Figure D)
6
Remove (4) screws securing the
radio. Disconnect and remove the
radio.
7
A
B
C
D
To Next Page
