99-6511 DASH DISASSEMBLY
JEEP WRANGLER 2007-2010
A
1
2
3
45
6
1
2
3
4 5
6
B
11
1
Remove (2) Phillips screws exposed
behind lower center panel. ( Figure A)
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
3
Unclip and remove the lower center
trim below a/c controls. (
Figure A)
2
Remove (2) Phillips screws exposed
behind upper center panel. ( Figure A)
5
Unclip and remove entire panel
surrounding radio and climate
controls, including a/c vents.
6
Remove (4) 7MM screws securing
radio. Unplug and remove radio.
(
Figure B)
7
Unclip and remove the upper center
trim starting towards the rear of the
panel. (
Figure A)
4
Continue to kit assembly.
