Metra Electronics 99-6511 - ISO Mount Radio Provision Assembly

99-6511 KIT ASSEMBLY
16
A
B
ISO MOUNT RADIO PROVISION WITH POCKET
Mount the ISO Brackets to the radio
using the screws supplied with the
radio.
(Figure A)
1
Slide the radio into the radio opening
until it snaps into place. (Figure B)
2
Snap the ISO Trim Plate onto the front
of the Radio Housing. (Figure B)
3
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
