3
99-7424 KIT ASSEMBLY
DIN RADIO PROVISION WITH POCKET
Slide the DIN cage into the Single DIN
Radio Housing and secure by bending
the metal locking tabs outward.
1
Slide the aftermarket radio into the
cage until it snaps into place.
(Figure B)
2
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
A
B
To Next Page
