99-7607B DASH DISASSEMBLY
NISSAN 370Z 2009-UP
D
isconnect the negative battery
terminal to prevent an accidental
short circuit.
1
AUTOMATIC SHIFT MODELS:
Unclip and remove the small shifter
trim panel including the hazard
switch.
(Figure A)
Unclip and remove the large shifter
trim panel.
(Figure B)
NOTE:
MANUAL SHIFT MODELS:
The shift trim is one piece, unsnap care-
fully and set aside.
2
Continue on page 2 .
3
Remove (1) Phillips screws from each
side panel on the center console at
the bottom of the radio panel then
unclip and remove the panels.
(Figure C)
A
B
C
