99-8205
KIT ASSEMBLY
3
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down. (
Figure E)
5
Slide the aftermarket head unit into
the cage and secure. (
Figure F)
6
E
F
DIN HEAD UNIT PROVISION
D
#6x1/4” Screws
#6x1/4” Screws
Two
#8x3/8” Screws
Mount the rear support to the back
of the pocket with (2) #8X3/8”
Phillips screws. (
Figure D)
4
