5
ISO DIN HEAD UNIT PROVISION
99-8205
KIT ASSEMBLY
Mount the ISO Brackets to the head
unit with the screws supplied with
the unit.
( Figure E)
5
Mount the rear support to the back
of the pocket with (2) #8x3/8”
Phillips screws.
( Figure D)
4
Slide the the head unit into the radio
opening until the side clips engage.
( Figure F)
6
Snap the Trim plate into the Radio
Housing.
( Figure F)
7
#6x1/4” Screws
#6x1/4” Screws
Two
#8x3/8” Screws
E
D
F
