99-8903B KIT ASSEMBLY
A
B
2
Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from Metra
or AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
1
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down. (Figure A)
2
Slide the aftermarket head unit into
the cage and secure. (Figure B)
3
Reassemble dash in reverse order of
disassembly.
4
2010 SUBARU LEGACY / OUTBACK
DIN HEAD UNIT PROVISION
