99-8903B KIT ASSEMBLY
A
B
3
Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from Metra
or AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
1
Mount the ISO Brackets to the head
unit with the screws supplied with
the unit. (Figure A)
2
Slide the head unit into the radio
opening until the side clips engage.
(Figure B)
3
Snap the Trim plate into the Radio
Housing. (Figure B)
4
Reassemble dash in reverse order of
disassembly.
5
2010 SUBARU LEGACY / OUTBACK
ISO DIN HEAD UNIT PROVISION
