10
Snap the double DIN trim-plate onto
the radio housing.
(Figure D)
5
Continue with final assembly.
6
TWO ISO UNITS PROVISION
99-8151
KIT ASSEMBLY
D
Align and engage the (3) tabs on the
bottom of the climate controls to the
top edge of the radio housing
assembly. Secure the climate con-
trols to the assembly using the (4)
factory Phillips screws previously
removed from the climate controls.
4
