99-8151
1
NOTE: Disconnect the negative
battery terminal to prevent an
accidental short circuit.
1
Using a small flat blade screwdriver,
unsnap and remove the liner from
the tray above the center vents.
(Figure A)
2
LEXUS IS 300 2001-2005
Remove (2) Phillips screws from
inside the tray.
(Figure B)
3
Using a small flat blade screw driver,
unsnap and remove the center trim
panel including vents and tray.
(Figure C)
4
DASH DISASSEMBLY
A
B
C
