METREL Earth 2/3 User Manual

MI 2126 Earth 2/3 Instrument description
7
2.3 Connector panel
Use original test accessories only!
Never connect instrument to high voltage!
H
S
E
1 2
3
Figure 2. Connector panel
Legend:
1 Blue – test terminal H
2 Red - test terminal S
3 Black – test terminal E
2.4 Base
R
EARTH
Ser.No .
1
2
4
3
Ser.No.
5
F
u
s
e
Figure 3. Base
