SLIDE POSITION TO MAXIMIZE
3" PAN CAPACITY OF UNIVERSAL SLIDES
Full Height
RPC5-13-U9
(includes slides and uprights)
SLIDE INSTALLATION
The universal rack
uprights or lip load
slides have been
installed at the factory.
If removed for cleaning,
reinstall by hanging
them on the shoulder
rivets on the side walls
of the cabinet.
INSTALLATION AND SET-UP (continued)
TOP VIEW
29B
29A
RPC5-13-URT5
RPC5-13-URT5
RPC5-13-URT7
29B
Slides sold in pairs. For additional pair of wire slides, order C5-USLIDEPR-C for Chrome or
C5-USLIDEPR-S for Stainless Steel. To order individual universal uprights only, see item #’s 29A, 29B.
3/4 Height
RPC5-13-U7
(includes slides and uprights)
1/2 Height
RPC5-13-U5
(includes slides and uprights)
