METRON MP430 Series User Manual

Page 9 of 25
2 CONFIG
1) ANALOG SIGNALS
2) AUXILLIARY ALARMS
1 CONFIG
1) SYSTEM SETPOINTS
2) USER PREFERENCES
3) TECH SCREENS
# 1 EVENT DETAILS
System in Off
Mode Occurred
10/16/04 13:15:15
# 1 EVENT LOG
System in Off
Mode Occurred
10/16/04 13:15:15
# 1 ALARM DETAILS
Pump Failed To
Start Alarm Occurred
10/16/04 07:32:15
# 1 ALARM LOG
Pump Failed To
Start Alarm Occurred
10/16/04 07:32:15
# 1 ALARM DETAILS
Pressure: 83.2psi
System Auto:Yes
Pump Running:No
# 1 EVENT DETAILS
Pressure: 83.2psi
System Auto:Yes
Pump Running:No
# 1 ALARM DETAILS
Phase A Amps 0
Phase B Amps 0
Phase C Amps 0
# 1 ALARM DETAILS
Phase AB Volt 460
Phase BC Volt 461
Phase AC Volt 464
# 2 ALARM LOG
Supvr Power Failure
Alarm Cleared
10/16/04 07:09:48
# 2 EVENT LOG
Pump Failed To
Start Alarm Occurred
10/16/04 07:32:15
# 3 ALARM LOG
Motor Overload
Alarm Occurred
10/16/04 06:49:03
# 3 EVENT LOG
Supvr Power Failure
Alarm Cleared
10/16/04 07:09:48
PRESSURE LOG
10/16/04 17:52:45
112 psi
Skip Rate:[EACH ]
PRESSURE LOG
10/16/04 17:52:30
112 psi
Skip Rate:[EACH ]
PRESSURE LOG
10/16/04 17:52:15
113 psi
Skip Rate:[EACH ]
SYSTEM LOGS
1) Alarm Log
2) Event Log
3) Pressure Log
1 SYSTEM STATUS B1
PRES STRT AB 460V
110 100 BC 461V
psi psi AC 460V
4 SYSTEM STATUS
Pump run Hr 0.0
# of Starts 0
Fri12/15/05 09:51:38
3 SYSTEM STATUS
Pump Countdown Tmr
0min Until Start
0min Until Stop
6 SYSTEM STATUS
Firmware Ver SV 1.1
Commissioned Date:
10/15/04
5 SYSTEM STATUS
Controller Power
On Time: 18.5 Hrs
Mon10/20/04 17:53:26
Continued on next
page.
| |
| |
| |
| |
| |
| |
| |
| |
| |
AUTO MANUAL TEST
STATUS
SYSTEM
LOGS
SYSTEM
1
CONFIG
2
METRON OID100
SILENCE/
OFF
ESC
RESET/
POWER
PRINT
3
ENTER
CHANGE/
2 SYSTEM STATUS
Phase A 125 Amps
Phase B 124 Amps
Phase C 125 Amps
# 1 EVENT DETAILS
Phase AB Volt 460
Phase BC Volt 461
Phase AC Volt 464
# 1 EVENT DETAILS
Phase A Amps 0
Phase B Amps 0
Phase C Amps 0
OID Screen Map
