METRON MP430 Series User Manual

Page 10 of 25
301 TECH SCREENS
Controller Model
Number
[ MP300]
303 TECH SCREENS
Nominal System
Voltage
[480]VAC 120-7200
304 TECH SCREENS
CPT Primary Voltage
Rating
[ 480] 120-7200
305 TECH SCREENS
Current Transformer
Ratio
[1200] /5 1-9999
306 TECH SCREENS
Restart Time
Delay
[ 3]sec 0-99
307 TECH SCREENS
Motor Full Load
Amps
[ 124]Amps 0-999
308 TECH SCREENS
Low Voltage
Trip Percent
[85]% 50-99
309 TECH SCREENS
Low Voltage
Time Delay
[ 5]sec 0-99
315 TECH SCREENS
Single Phase Alarm
% of FLA
[ 5]% 0-99
314 TECH SCREENS
Start Transition
Time Delay
[ 2]sec 0-10
313 TECH SCREENS
Phase Loss
Time Delay
[5]sec 0-99
312 TECH SCREENS
Phase Loss % of
Nominal Voltage
[70]% 0-99
311 TECH SCREENS
High Voltage
Time Delay
[ 5]sec 0-99
310 TECH SCREENS
High Voltage Alarm
% of Nominal
[125]% 0-999
302 TECH SCREENS
Transfer Switch
Supplied
[Yes]
2 CONFIG
1) ANALOG SIGNALS
2) AUXILLIARY ALARMS
1 CONFIG
1) SYSTEM SETPOINTS
2) USER PREFERENCES
3) TECH SCREENS
210 USER PREFERENCES
Selective Range
Printing
[ 1] Before 1-99
209 USER PREFERENCES
Auto Print Each
Event Log Entry
[No ]
208 USER PREFERENCES
Auto Print Each
Pressure Log Sample
[No ]
207 USER PREFERENCES
Time Between
Pressure Log Samples
[ 15] seconds 15-999
206 USER PREFERENCES
System Pressure Drop
Event Time Span
[15] seconds 0-20
205 USER PREFERENCES
Low Pressure Event
Trip Pressure
[5]psi 0-999.9
204 USER PREFERENCES
Log System Pressure
Drop Events
[Yes]
203 USER PREFERENCES
Set System Day
Of The Week
[Sun]
202 USER PREFERENCES
Set System Date
[02/16/03]
211
USER PREFERENCES
Selective Range
Printing
[ 1] After 1-99
201 USER PREFERENCES
Set System Real
Time Clock
[17:03:52]
102 SYSTEM SETPOINTS
Pump Stop
Pressure
[110.0]psi 0-999.9
115 SYSTEM SETPOINTS
Supervisory Power
Delay Time
[ 2] sec 0-99
114 SYSTEM SETPOINTS
Supervisory Power
Option
[No]
111 SYSTEM SETPOINTS
Auto Weekly Pump
Test Start Time
[10:00:00]
112 SYSTEM SETPOINTS
Auto Weekly Test
Length Of Run Time
[30] minutes 30-99
113 SYSTEM SETPOINTS
Stop Motor during
Test on Alarm
[No]
103 SYSTEM SETPOINTS
Pump Start
Delay Time
[ 10] seconds 0-999
104 SYSTEM SETPOINTS
Pump Automatic
Stop Enabled
[Yes]
105 SYSTEM SETPOINTS
Pump Minimum
Run Time
[30]minutes 30-99
109 SYSTEM SETPOINTS
Automatic Weekly
Test Run
[Yes]
101 SYSTEM SETPOINTS
Pump Start
Pressure
[100.0]psi 0-999.9
414 ANALOG SIGNALS
Phase BC Voltage
Slope:
[0.729750]
413 ANALOG SIGNALS
Phase AB Voltage
Offset:
[6.52430]
412 ANALOG SIGNALS
Phase AB Voltage
Slope:
[0.729750]
411 ANALOG SIGNALS
Minimum Volts
[10] 0-9999
410 ANALOG SIGNALS
Analog Input 03
Minimum Counts
[ 0]
402 ANALOG SIGNALS
Analog Input 1 651
Minimum Counts
[ 200]
401 ANALOG SIGNALS
Analog Input 01
Offset:
[- 75.2568]
400 ANALOG SIGNALS
Analog Input 01
Slope:
[0.2135678]
502 AUX USER PROGRAM
AUX# 1
Input Number
[30] 0-40
512 AUX USER PROGRAM
AUX# 1
Output3 Number
[ 0] 0-19
515 AUX USER PROGRAM
AUX# 1
Text Message Number
[ 0] 0-27
514 AUX USER PROGRAM
AUX# 1
Record In Alarm Log
[No ]
513 AUX USER PROGRAM
AUX# 1
Record In Event Log
[No
]
507 AUX USER PROGRAM
AUX# 1
Horn Enabled
[No ]
511 AUX USER PROGRAM
AUX# 1
Output2 Number
[ 0] 0-19
510 AUX USER PROGRAM
AUX# 1
Output1 Number
[ 0] 0-19
508 AUX USER PROGRAM
AUX# 1
Horn Silence
[No ]
509 AUX USER PROGRAM
AUX# 1
LED Number
[ 0] 0-24
504 AUX USER PROGRAM
AUX# 1
Trip Time
[ 0]sec 0-999
505 AUX USER PROGRAM
AUX# 1
Reset Time
[ 0]sec 0-999
506 AUX USER PROGRAM
AUX# 1
Auto Reset Enabled
[Yes]
503 AUX USER PROGRAM
AUX# 1
Input Contact Type
[NO ]
501 AUX USER PROGRAM
AUX# 1
Enabled
[Yes]
110 SYSTEM SETPOINTS
Auto Weekly Test
Day Of The Week
[Mon]
106 SYSTEM SETPOINTS
Ramp Stop Option
MP700
[Yes]
108 SYSTEM SETPOINTS
Solenoid Drain
Valve Option
[Yes]
107 SYSTEM SETPOINTS
Ramp Stop Option
Time
[10]sec 1-99
212 USER PREFERENCES
High Discharge Press
Alarm Option
[ No]
213 USER PREFERENCES
High Discharge
Alarm Pressure
[100] 1-999
214 USER PREFERENCES
High Discharge Alarm
Time Delay
[ 8]sec 0-99
215 USER PREFERENCES
Low Discharge Press
Alarm Option
[ No]
403 ANALOG SIGNALS
Analog Input 01 651
Maximum Counts
[ 800]
404 ANALOG SIGNALS
Analog Input 1 651
Minimum PSI
[ 3] 0-10
405 ANALOG SIGNALS
Analog Input 02
Slope
[ 0.0094996]
406 ANALOG SIGNALS
Analog Input 02
Offset
[-75.2568]
407 ANALOG SIGNALS
Analog Input 02 651
Minimum Counts
[ 0]
408 ANALOG SIGNALS
Analog Input 03
Slope
[0.0094996]
409 ANALOG SIGNALS
Analog Input 03
Offset
[-75.2568]
OID Screen Map (continued)
