METRON MP430 Series User Manual

Page 11 of 25
318 TECH SCREENS
Use Motor Current
for Pump Running Sig
[Yes]
316 TECH SCREENS
Single Phase Loss
Time Delay
[5]seconds 0-99
220 USER PREFERENCES
LCD Back Light Mode
0=Always on
[0]] 1=Power Save
221 USER PREFERENCES
Language Select
[English]
222 USER PREFERENCES
Change User Password
Level 1
[****]
120 SYSTEM SETPOINTS
Shutdown On Low
Intake Trip Time
[ 0]seconds 0-999
119 SYSTEM SETPOINTS
Shutdown On Low
Intake Pressure/Lvl
[No ]
118 SYSTEM SETPOINTS
Pressure Transducer
Failure Pump Start
[ No]
117 SYSTEM SETPOINTS
Supvervisory Power
Fail Start Dly Time
[ 1]minutes 0-500
116 SYSTEM SETPOINTS
Supervisory Power
Failure Startup
[Yes]
ANALOG INPUT COUNTS
649 1176 1221 0
0 0 0 0
0 0
415 ANALOG SIGNALS
Phase BC Voltage
Offset:
[6.52430]
121 SYSTEM SETPOINTS
Low Intake Shutdown
Auto Reset
[ No]
124 SYSTEM SETPOINTS
Deluge Valve
Pump Start
[No]
123 SYSTEM SETPOINTS
Pressure Switch
Pump Start
[No ]
122 SYSTEM SETPOINTS
Low Intake Shutdown
Auto Reset Time
[ 0]seconds 0-999
216 USER PREFERENCES
Low Discharge
Alarm Pressure
[100] 0-999
217 USER PREFERENCES
Low Discharge Alarm
Time Delay
[ 8]sec 0-99
219 USER PREFERENCES
No Load Time
Time Delay
[ 8]sec 0-99
218 USER PREFERENCES
No Load Amps %
of FLA
[ 5] 0-99
317 TECH SCREENS
Motor Run % of
FLA
[20]% 0-99
319 TECH SCREENS
Overload Alarm
% of FLA
[125]% 100-199
320 TECH SCREENS
Overload Alarm
Time Delay
[3]sec 0-99
322 TECH SCREENS
Motor Run Amps
Time Delay
[5]sec 0-99
323 TECH SCREENS
Motor Start
Time Delay
[10]sec 0-99
324 TECH SCREENS
Under Frequency
% of Nominal
[2
5] 0-99
325 TECH SCREENS
Under Frequency
Time Delay
[5]sec 0-99
326 TECH SCREENS
Over Frequency
% of Nominal
[25]% 0-999
321 TECH SCREENS
Start on Single
Phase Loss
[Yes]
327 TECH SCREENS
Over Frequency
Time Delay
[5]sec 0-99
328 TECH SCREENS
Alarm log 31/2
Event log 50/ 4
Pr. log 0/29333
329 TECH SCREENS
System Commissioned
Date
[00/00/00]
330 TECH SCREENS
Change Tech Password
[******]
331 TECH SCREENS
Password Logout
Time
[5]min 1-15
416 ANALOG SIGNALS
Phase AC Voltage
Slope:
[0.729750]
417 ANALOG SIGNALS
Phase AC Voltage
Offset:
[6.52430]
418 ANALOG SIGNALS
Minimum Amps
[10] 0-9999
421 ANALOG SIGNALS
Phase B Amps
Slope:
[ 2.9635]
424 ANALOG SIGNALS
Phase C Amps
Offset:
[36.9270]
423 ANALOG SIGNALS
Phase C Amps
Slope:
[ 2.9635]
422 ANALOG SIGNALS
Phase B Amps
Offset:
[36.9270]
420 ANALOG SIGNALS
Phase A Amps
Offset:
[36.9270]
419 ANALOG SIGNALS
Phase A Amps
Slope:
[ 2.9635]
425 ANALOG SIGNALS
Set Volts/Amps Slope
Offset to Fact
Dflt[Yes]
223 USER PREFERENCES
Reversed Phase
order (1-3-2)
[No]
Daughter board
counts
649 1176 1221 0
0 0 0 0
