Range ARS 2302 FS ARS 2305 FS ARS 2310 FS
24V supply
*) plus current consumption of a
possibly connected holding brake
and I/Os
24 VDC [± 20%] (1 A) *)
Internal brake resistor [X9]:
Brake resistance 68 Ω
Pulse power 8,5 KW
Continuous power 110 W
Threshold limit 760 V
External brake resistor [X9]:
Brake resistance external ≥ 40 Ω
Continuous power ≤ 5000 W
Permissible operating voltage ≥ 800 V
Motor connection specifications [X6]:
Specifications for operation with 3x 400 VAC [± 10%], 50 Hz, with an output stage clock frequency of 5 kHz
Output power 1,5 kVA 3 kVA 6 kVA
Max. output power for 3 s 3 kVA 6 kVA 12 kVA
Output current 2,5 A
RMS
5 A
RMS
10 A
RMS
Max. output current for 0.5 s and
f
s
> 5Hz
Max. output current for 3 s
10 A
RMS
7.5 A
RMS
20 A
RMS
10 A
RMS
40 A
RMS
(for 0,3s)
20 A
RMS
Max. mains current for continuous
operation
2,5 A
RMS
5 A
RMS
9 A
RMS
Output stage clock frequency 4…16 kHz (software programmable)
As a guideline: Power
loss/efficiency (with regard to the
rated output power)
typical 8% / 92%
Maximum motor cable length for interference emission as per EN 61800-3:
Category C2 (ex first ambient with
limited availability)
Switch cabinet assembly
l ≤ 50m
Category C3 (ex second ambient)
(industrial area)
l ≤ 50m
Cable capacity of a phase against
shield or between two lines
C‘ ≤ 200pF/m
Motor temperature monitoring:
Digital sensor
These contacts have a PELV
(Protective extra-low voltage).
Normally closed contact: R
cold
< 500 Ω R
hot
> 100 kΩ
