4 Mechanical installation
4.1 Important notes
Only use the servo positioning controller ARS 2300 FS as a built-in device for switch cabinets.
Mounting position vertical with supply lines
[X9] on top.
Mount to control cabinet plate using a fastening strap.
Installation spaces: Keep a minimum distance of 100 mm to other components each above and
underneath the device to ensure sufficient venting.
The servo positioning controller ARS 2300 FS may be installed adjacently in one switch cabinet
without a gap, proper usage and installation on a heat-dissipating rear panel provided. Please
note that excessive heat may cause premature aging and/or damaging of the device. In case the
servo positioning controller ARS 2300 FS are subject to high thermal stress, a space of 75 mm is
recommended!
The connections of the following illustrations for the servo positioning controller
ARS 2302 FS also apply to the servo positioning controller ARS 2305 FS and
ARS 2310 FS!
